Ubiquiti Networks PBE-M5-300 network antenna Sector antenna 22 dBi

Write a review
89.46
28 days
PBE-M5-300
IN STOCK
+

Ubiquiti NanoBeam PBE-M5-300 radio system

The Ubiquiti NanoBeam PBE-M5-300 radio system works in the 5 GHz band and complies with the 802.11n MIMO 2x2 standard.

This product is equipped with a 560 MHz Atheros MIPS 74KC processor. The device uses 64 MB internal memory and 8 MB flash drive memory.



 width=


Construction

Its perfected design allows it to be used in areas with high interference levels. By integrating the antenna emitter with the radio module/access point the producer created a new, versatile quality. It can be used at temperatures ranging from -40 to 70 degrees Celsius.



 width=

Antennas

The dual band 300 mm diameter antenna is characterised by a maximum gain of 22 dBi. The device is powered by PoE. It is also equipped with 1 Ethernet 10/100 Mb/s port. The device uses InnerFeed technology which results in an increase in bandwidth and interference resistance.



 width=



Key features

  • works in the 5 GHz band
  • 150 Mbps bandwidth
  • 22 dBi antenna gain
  • 20 km range
  • durable construction
  • router or bridge mode
  • easy installation
  • InnerFeed technology
  • AirMax technology



 width=



Installation

The PBE-M5-300 can be installed effortlessly and quickly. The installation of the AF-5X is easy and intuitive.





Use

This device is very versatile. It can work in Router and Bridge modes.



 width=





Comparison



 width=

PBE-M5-620

 width=

PBE-M5-400

 width=

PBE-M5-300

 width=

PBE-M2-400

Frequency Band 5 GHz 5 GHz 5 GHz 2.4 GHz
Antenna Gain 29 dBi 25 dBi 22 dBi 18 dBi
Dish Reflector 620 mm 400 mm 300 mm 400 mm
Network Interface 10/100/1000 10/100/1000 10/100 10/100
Throughput 150+ Mbps 150+ Mbps 150+ Mbps 150+ Mbps
Range 30+ km 25+ km 20+ km 20+ km



Manufacturer's content

 Read more in the manufacturer's documentation

 Read the manual



Specifications



Basic data
Item nameUbiquiti Networks PBE-M5-300 network antenna Sector antenna 22 dBi
Product symbolPBE-M5-300
Hierarchy by CATEGORY
  • Computers & Peripherals
  • Networking
  • Networking Hardware
  • Network Antennas
Hierarchy by MANUFACTURER
  • Ubiquiti
Package sizes (HxWxL)150 x 330 x 330 mm
Weight gross1.50 kg
Logistics data
Harmonized System (HS) code
  • 85177100
Weight & dimensions
Height
  • 256.00 millimeter
Width
  • 325.00 millimeter
Depth
  • 325.00 millimeter
Weight
  • 1203.00 gram
Certificates
Certification
  • FCC, IC, CE
icecat_automatic_48024_76
  • RoHS
Packaging content
Quantity per pack
  • 1.00 pcs
Features
Antenna type
  • Sector antenna
Survival wind speed
  • 200.00 km/h
Power handling
  • 6.00 W
Product color
  • White
Performance
Frequency band
  • 5 GHz
Antenna gain level (max)
  • 22 dBi
Despite making every effort, we cannot guarantee that the presented photos and descriptions do not contain errors; however, this cannot become the basis for claims.
