Teltonika TSW101 Switch AUTOMOTIVE PoE+

Write a review
77.83
TASK LTD
28 days
TSW101000000
IN STOCK
+
The Teltonika TSW101 is designed specifically for the automotive industry, featuring five Basic Switching RJ-45 Ethernet ports that support Gigabit Ethernet (10/100/1000). This automotive PoE+ switch enables the connection and powering of multiple devices through the same interfaces, facilitating high bandwidth connectivity. It includes a MAC address table capable of holding 2000 entries and boasts a switching capacity of 10 Gbit/s. Adhering to networking standards such as IEEE 802.3, IEEE 802.3az, and IEEE 802.3u, the switch ensures compatibility and efficient energy usage. The power is supplied via a terminal block (2-pin) connector, simplifying the installation process. The integration of Power over Ethernet (PoE) technology allows for the transfer of electrical power, along with data, to devices over the network cables, reducing the need for additional power supplies. This switch is an effective solution for enhancing network performance and simplifying device management in automotive environments.

Basic data
Item nameTeltonika TSW101 Switch AUTOMOTIVE PoE+
Product symbolTSW101000000
Hierarchy by CATEGORY
  • Computers & Peripherals
  • Networking
  • Networking Hardware
  • Network Switches
Hierarchy by MANUFACTURER
  • Teltonika
Package sizes (HxWxL)35 x 150 x 175 mm
Weight gross0.44 kg
Logistics data
Harmonized System (HS) code
  • 851762
Weight & dimensions
Height
  • 95.00 millimeter
Width
  • 115.00 millimeter
Depth
  • 32.00 millimeter
Weight
  • 354.00 gram
Power
Power source
  • DC
Input voltage
  • 9 - 30 V
Power consumption (typical)
  • 0.64 W
Power consumption (max)
  • 2.31 W
Data transmission
Switching capacity
  • 10.00 Gb/s
MAC address table
  • 2000 entries
Certificates
Certification
  • CE, REACH, RoHS, WEEE TSW101 CE TSW101 UKCA TSW101 FCC TSW101 IC TSW101 CB TSW101 RCM E-Mark
Design
International Protection (IP) code
  • IP30
Housing material
  • Aluminum
LED indicators
  • Power, Status
Product color
  • Metallic
Network
Networking standards
  • IEEE 802.3
  • IEEE 802.3az
  • IEEE 802.3u
Ethernet LAN data rates
  • 10,100,1000 Mbit/s
Ports & interfaces
Basic switching RJ-45 Ethernet ports type
  • Gigabit Ethernet (10/100/1000)
Power connector
  • Terminal block (2-pin)
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget
  • 120.00 W
Power over Ethernet (PoE) power per port
  • 30.00 W
Power over Ethernet (PoE) type supported
  • Passive PoE
Management features
Switch layer
  • L2
Switch type
  • Unmanaged
Despite making every effort, we cannot guarantee that the presented photos and descriptions do not contain errors; however, this cannot become the basis for claims.
