Ubiquiti Networks HORN-5-45 network antenna Horn antenna 15.5 dBi

Return period: 28 days

CODE: HORN-5-45

Ubiquiti HORN-5-45. Antenna gain level (max): 15.5 dBi, Frequency band: 5.15 - 5.85 GHz, Horizontal beam width: 45°. Antenna type: Horn antenna,...

Full description

€89.46

+ −

Vendor: TASK LTD

€89.46

Description
Reviews

Ubiquiti HORN-5-45. Antenna gain level (max): 15.5 dBi, Frequency band: 5.15 - 5.85 GHz, Horizontal beam width: 45°. Antenna type: Horn antenna, Polarization: Dual polarization, Voltage Standing Wave Ratio (VSWR): 1.7:1. Height: 3.78" (96 mm), Diameter: 6.89" (17.5 cm), Weight: 2.95 lbs (1.34 kg). Quantity per pack: 1 pc(s)

Basic data
Item name	Ubiquiti Networks HORN-5-45 network antenna Horn antenna 15.5 dBi
Product symbol	HORN-5-45
Hierarchy by CATEGORY	Computers & Peripherals Networking Networking Hardware Network Antennas
Hierarchy by MANUFACTURER	Ubiquiti
Package sizes (HxWxL)	220 x 200 x 130 mm
Weight gross	0.80 kg
Logistics data
Harmonized System (HS) code	85177100
Weight & dimensions
Height	96.00 millimeter
Diameter	175.00 millimeter
Weight	1340.00 gram
Packaging content
Quantity per pack	1.00 pcs
Features
Antenna type	Horn antenna
Survival wind speed	200.00 km/h
Isolation	17.00 dB
Polarization	Dual polarization
Voltage Standing Wave Ratio (VSWR)	1.7:1
Product color	White
Performance
Frequency band	5.15 - 5.85 GHz
Antenna gain level (max)	15.5 dBi
Horizontal beam width	45.00 degrees
Vertical beam width	45.00 degrees
